Quick DetailsPlace of Origin: Zhejiang, China (Mainland)Brand Name: Ocean WeldingModel Number: AWS E309LT1-1Material: Stainless SteelDiameter: 1.2mmMelting Po...
Quick Details
Place of Origin: Zhejiang, China (Mainland)
Brand Name: Ocean Welding
Model Number: AWS E309LT-1
Material: Stainless Steel
Diameter: 1.2mm
Melting Point: International Standard
Weight: 15kgs/spool
Packaging & Delivery
| Packaging Details: | 15kgs/spool,1ton/pallet |
| Delivery Detail: | 20-25days |
Specifications
Model Number:AWS E309LT-1
Brand Name:Ocean Welding
Size:1.2mm
Product Description
E309LT-1 is a titania type, all-position,flux-cored wire designed for MAG welding of low carbon 22% Cr-12% Ni stainless steels. It is also used for dissimilar weld joints between high strength, mild steels and low-alloyed QTsteels, stainless, ferritic Cr- and austenitic Cr-Ni-steels, manganese steels. The weld metal contains comparatively much more ferrite in their austenitic, therefore providing better weldability together with superior heat and corrosion resistance.
AWS Specification AWS A5.22
AWS Classification E309LT-1/-4
Welding Current
GMAW-DCEP
Typical Wire Chemistry
(as welded with 100% CO2
shielding gas)
C 0.026
Si 0.53
Mn 1.32
S 0.01
P 0.017
Cr 23.62
Ni 13.2
Mo 0.05
Typical Mechanical Properties
(As Welded)
Tensile Strength, psi 79,800
% Elongation 40
Welding Positions
All positions
Available Diameters and suggested
Operating Range in Amps
.035" 70 - 160
.045" 135 - 250
