1. Quick Product Overview
| Item | Specification |
|---|---|
| Place of Origin | Zhejiang, China (Mainland) |
| Brand Name | Ocean Welding |
| Model Number | Welding Electrode E6010 |
| Material | Non-alloy steel with cellulose coating |
| Diameter Options | 2.0mm, 2.5mm, 3.2mm, 4.0mm, 5.0mm |
| Length | 300mm - 350mm |
| Welding Current | 50A - 240A |
| Operating Current | AC/DC (DC reverse polarity recommended) |
| Operating Temperature | Normal |
| Color | Grey-white / Blue |
| OEM Service | Acceptable |
2. Product Features
All-position Welding: Suitable for flat, vertical, horizontal, and overhead welding scenarios.
Strong Arc Penetration: Enables "single-sided welding with double-sided forming"-ideal for pipeline and structural welding.
Low Slag, Easy Cleanup: Produces minimal welding slag; slag shell peels off easily, improving work efficiency.
High Welding Efficiency: Fast welding speed with smooth, aesthetically pleasing weld appearance.
3. Mechanical Properties of Deposited Metal
| Test Item | Guarantee Value (GV) | Typical Value | Unit |
|---|---|---|---|
| Tensile Strength (T.S) | ≥420 | 500 | MPa |
| Yield Strength (Y.S) | ≥330 | 405 | MPa |
| Elongation (EL.) | ≥22 | 28 | % |
| Charpy Impact Energy (CVN) | ≥27 | 96 | J |
4. Application Scope
Specialized for low carbon steel structure welding, mainly used in:
General carbon steel pipes (e.g., oil/gas pipelines, water supply/drainage pipes).
Bottom layer, filling layer, and capping layer welding of same-type low carbon steel structures.
5. Packaging & Delivery
| Packaging Level | Specification |
|---|---|
| Inner Box | 5kgs per box |
| Outer Carton | 20kgs (4 inner boxes per outer carton) |
| Pallet | 1 ton per pallet |
Port Options: Shanghai / Ningbo / Yiwu
Lead Time: Within 20 days after order confirmation
6. Usage & Storage Notes
Pre-welding Preparation:
Normally, no baking is required before welding.
If the electrode is damped (e.g., coating discoloration, agglomeration), bake at 70-80℃ for 0.5-1 hours before use.
Welding Operation:
Recommend DC reverse polarity connection for optimal arc performance.
Adjust welding current according to electrode diameter and welding position.
